TECHNICAL
DATAS
Données techniques |
Status
Statut
|
public
|
Current state
Etat actuel
|
|
Start
Début
|
1889
|
End
Fin
|
...
|
Rebuildings
Reconstructions |
1934, 1974
|
Type of funicular
Type de funiculaire
|
|
Type of tracks
Type de voie
|
|
Type of energy
Type d'énergie
|
1890 - 1934
1934 - ...
|
Bottom Station
Gare basse |
Tomiceva (126 m)
|
Top Station
Gare haute |
Gornji grad (156,5 m)
|
Length
Longueur |
66 m
|
Diff. of levels
Dénivellé |
30,5 m
|
Max. Gradient
Pente maximum |
52 %
|
Cable
Câble |
22 mm
|
Gauge
Ecartement |
1,2 m
|
Time of a ride
Durée d'une course |
55"
|
Speed
Vitesse |
1,5 m/s
|
Max Payload
Charge utile |
2240 kg
|
Cabins
Voitures |
2 x 28 pers.
Schiffswerft, Korneuburg, Austria
|
Power unit
Moteur |
Waagner, Vienna & Braca Kavuric
|
Buildings
Bâtiments |
Borongaj Zagreb
|
